| Model NO. | DTCA121-10CL | Magnification(x) | 2.0 | ||||
| Object Field of View (Φmm) | 10.0 | Working Distance (mm) | 63±1 | ||||
| Max Sensor Size (Φmm) | 20(1.2") | Best Aperture (F/#) | 6.6 | ||||
| Telecentricity typical (max) (deg) | <0.1 | Distortion typical(max) (%) | <0.2 | ||||
| MTF30 (lp/mm) | >142 | Depth of Field (mm) | ±0.07@F6.6 | ||||
| Length of I/O (mm) | 260±1 | Mount | C | ||||
| Length(mm) | 179 | Weight(kg) | 0.5 | ||||
| Coaxial Illumination Port Option | YES | Iris Adjustable | NO | ||||
| Back Focal Length Adjustable | NO | ||||||
| Field of View (mm × mm) | 1.2" IMX530/540 (14.6x12.6) | 7.3x6.3 | |||||
Dimensions
